AVR 370
7.2-channel, wireless, network-connected A/V receiver with AirPlay
Sold from 2013 until 2014
Made in: | China |
---|
Documents & Downloads
Specifications
- Power Requirement
- AC 230V/50–60Hz
- Power Consumption (full power/idle)
- 120W idle; 1405W maximum (7 channels driven)
- Transient intermodulation distortion (TIM):
- Unmeasurable
- Multichannel Power (all channels driven)
- 125 watts/ch, 20Hz – 20kHz, <0.07% THD, two channels driven @ 8 ohms, 6-ohm certified
- High Instantaneous Current Capability
- ±45 amps
- Output Level/Impedence (ohm)
- 1Vp-p/75 ohms
- Distortion (Mono/Stereo)
- 0.2%/0.3%
- Signal-to-Noise Ratio (Mono/Stereo dB)
- 70dB/68dB
- Input Level/Impedence (ohm)
- 1Vp-p/75 ohms
- Selectivity (±400kHz):
- 70dB
- Stereo Power
- 125 watts/ch, 20Hz – 20kHz, <0.07% THD, both channels driven @ 8 ohms, 6-ohm certified
- Distortion (1kHz, 50% mod):
- 50%, mod 0.8%
- Frequency Range (kHz)
- 520kHz – 1620kHz
- Usable Sensitivity (Loop)
- 500?V
- Input Sensitivity/Impedence
- 200mV/47k ohms
- Stereo Separation @ 1kHz (dB)
- 40dB @ 1kHz
- Signal-to-Noise Ratio (dB)
- 45dB
- Selectivity (±10kHz):
- 30dB
- Surround system adjacent-channel separation:
- Dolby Pro Logic® I/II
- Signal-to-noise Ratio (IHF-A) (dB)
- 100dB
- Bandwidth @ 1W (+0dB/–3dB)
- 10Hz – 130kHz
- Usable Sensitivity (IHF)
- 1.3?V/13.2dBf
- Frequency Range (MHz)
- 87.5MHz–108.0MHz
- Width (mm)
- 440mm
- Depth (in)
- 1/2" x 15" inches
- Height (in)
- 6-1/2" inches
- Height (mm)
- 165mm
- Depth (mm)
- 382mm
- Width (in)
- 17-5/16" inches
- Weight(kg)
- 8kg
- Image Rejection (dB)
- 80dB
- Video Frequency Response (Component Video)
- 10Hz – 8MHz (–3dB)
- Television Format
- PAL, NTSC
- IF Rejection (dB)
- 90dB
All of your entertainment sources in spectacular sound.
All of your entertainment sources in spectacular sound. Improve the sound and video from every one of your audio or video devices to a world of glorious, enveloping surround sound and video, up to the latest 4K technology. Even if you already have surround-sound speakers, the Harman Kardon® AVR 370 audio/video receiver’s 7.2-channel audio system will add the dimension of front height to your environment, along with dual subwoofers. The receiver’s Dolby® and DTS® technology will place every musical note and sound effect where it should be while the new lightweight, eco-friendly, digital power supply supports 125-watts-per-channel. And the receiver can handle virtually any medium or sound source. Eight HDMI® inputs, including one on the front panel, ensure connectivity to all your Blu-ray™ or DVD media, HDTV programs and video-game sources, while analog and digital audio input jacks connect you to your familiar legacy components. Built-in Wi-Fi® and AirPlay connectivity keep you cord-free while allowing you to play every song on your computer, tablet, mobile phone and MP3 device. An intuitive, high-definition graphical menu system, remote control, available mobile app and EzSet/EQ™ calibration make setup and operation seem almost too easy for a device this advanced. Your home is a place of pride, beauty and comfort. Bring it to life with sound that is beyond inspiring.
FAQs & How-Tos
-
Yes, download the Harman Kardon Remote app to do this.Was this helpful? Thank you for your feedback!
-
Yes, Zone 2 can play compatible contents of a USB stick inserted into the front panel of the receiver.Was this helpful? Thank you for your feedback!
-
No, upgrade can only be performed with a USB stick. There is no danger to the receiver if you try to upgrade through the wireless network, though.Was this helpful? Thank you for your feedback!
-
There may be more than one reasons for this problem, but one detail is important: if establishing the connection manually, do not advance the cursor after having written all characters in your password with the up and down arrows. If you jump to the next empty position after the last character, this will be interpreted as an added character in itself, and the password will be wrong.Was this helpful? Thank you for your feedback!
-
DVD and Blu-ray Disc copy protection only allows analog video output up to 576p resolution when playing DVDs and Blu-ray Discs. To view video at higher resolutions use the AVR’s HDMI inputs and HDMI output instead of its component video inputs and output.Was this helpful? Thank you for your feedback!
-
The Harman AVR App controls your receiver through your smartphone, which communicates via your wireless home network. Please make sure that your AVR is properly connected to your network router, with cable for the smaller models. If you have no wireless home network, you cannot use the app.Was this helpful? Thank you for your feedback!
-
Please place your AVR in full Standby by holding the Power Button for at least three seconds. Now, when you switch it ON again, the problem should have disappeared. Please note that Sleep Mode is not sufficient, you must use full Standby.Was this helpful? Thank you for your feedback!
-
Yes, on your computer, enter the IP address of the receiver in the internet browser. In the page that opens, it is possible to change the name.Was this helpful? Thank you for your feedback!
-
For your personal safety and to avoid possible damage to your equipment and speakers, it is always a good practice to turn off and unplug the AVR and ALL source equipment from the AC output before making any audio or video system connections.Was this helpful? Thank you for your feedback!
-
There are five possible reasons for the receiver shutting down. 1. There is a problem internally with the receiver. 2. There is a problem with one or more of your speakers. 3. There is a problem with one or more of your speaker wires. 4. There is a problem with the speaker wiring done on your system. 5. The unit is overheating. No ventilation. First, check the wiring at every speaker terminal at the back of your receiver and at the back of your speakers. A single strand of speaker wire crossing from one terminal to another would be enough to cause the amp to shut down or go into PROTECT. If you do not find any problems with any of the wiring, you should disconnect all speakers from your receiver. If the receiver continues to go into PROTECT, the problem is in the receiver. Please submit a case on the Contact Us page. They will be able to assist you. However, if it turns on, the problem is elsewhere. Begin reconnecting one speaker at a time. Eventually you will connect a speaker that will cause the receiver to shut down. At this point you have found your culprit. On the other hand, it may just be overheating. You must have at least 2 - 3 inches of space between the top of the unit and any shelf or component above the unit. The unit should not be inside a sealed compartment when being used. The unit must be able to breath. There are very powerful amps in these receivers. If they run too hot, they will shut down. An external fan can help this.Was this helpful? Thank you for your feedback!
