PZM11 LL
Professional flush-mount line-level boundary layer microphone
Getting started with your PZM11 LL
Register your product
Do you own this product? Register it here! And claim your warranty or service easily
Register nowDocuments & Downloads
Specifications
- Audio frequency bandwidth
- 80 - 20000 Hz
- Equivalent noise level
- 26 dB-A
- Sensitivity
- 5 mV/Pa
- Signal to Noise
- 68 dB-A
- Length
- 115 mm
- Width
- 70 mm
- Height
- 29 mm
- Net Weight
- 71 g
- Finish
- off-white
- Type
- screw material
- Voltage
- 12 to 48 V
- Retail
- Boundary Layer Microphone
Listen up!
The PZM11 professional boundary layer microphone is designed for security and surveillance applications. The PZM11 is characterized by a consistent pickup anywhere around the mic. Low frequencies below the voice range are rolled off to reduce the pickup of heating, ventilation or air-conditioning rumble (HVAC noise). The high-frequency response is boosted slightly to aid clarity and articulation. The PZM11 has a mic-level output and is powered by 12-48V phantom power. Electronics on the rear of the plate offer screw terminals, eliminating the need for connectors.
