C363
6 ½" In-Ceiling Loudspeaker
Getting started with your C363
Register your product
Do you own this product? Register it here! And claim your warranty or service easily
Register nowDocuments & Downloads
Product Specifications
- Height:Cutout dimensions (dia.)
- 8" (20.3 cm) • Square grille finished Height
- Width
- Square grille finished width
- Depth
- Mounting depth
- Weight
- 1.6 lb (0.8 kg) / Shipping weight
- Features
- Includes both round and square zero-bezel magnetic grilles • Round grille finished dimension (dia.)
- High-frequency Driver Components
- 1" aluminum dome swiveling tweeter with waveguide
- Low-frequency Driver Components
- 6 ½" Micro-Ceramic Composite (MCC) Cone, Cast-Polymer Frame Woofer
- Mounting
- C-2 fastening mechanism • Compatible with wall material thickness range
- Recommended Amplifier Power
- 10 - 120 Watts RMS
C363
Revel in-ceiling loudspeakers draw upon the same research, resources, and unique perspectives that put all our loudspeakers in a class by themselves. Each model offers a standard-setting low sonic coloration and freedom from distortion over a wide dynamic range.
FAQs & How-Tos
3 results
-
No, in-ceiling speakers cannot be used in the wall due to speaker dimensions. A wall is not deep enough to accommodate the depth of an in-ceiling speaker. For in-wall speakers, you can install them in the ceilings without any depth issues. However, for quality listening, we recommend using architectural speakers according to their intended purpose.Was this helpful? Thank you for your feedback!
-
In-wall speakers will work better for stereo listening because the speaker will be facing directly at you instead of above you. Note: Stereo imaging requires the listening position (“sweet spot”) to be dead center, equal distance, from the front left and right speakers.Was this helpful? Thank you for your feedback!
-
All of our in-wall/in-ceiling speakers are designed to be used in a wall without the need for a back-box. The specs provided are based on no back-box. However, when adding a back-box (really only possible when doing new construction), you will improve the low frequency response a bit, getting a tighter bass response.Was this helpful? Thank you for your feedback!
